Snowflake Data Clean Rooms: Custom Analysis Templates

This topic describes the provider and consumer flows needed to programmatically set up clean room, share it with a consumer, and run provider-side data analyses with custom templates in it. A provider-side data analysis with custom templates is one where the consumer does not have to bring in their datasets but simply wants to get aggregated insights about the provider’s datasets using the custom templates added by the provider.

It will cover the following over the End-to-End: Overlap Analysis Tutorial:

  1. Provider:

    a. Create a new custom template.

    b. Add it to the clean room.

  2. Consumer:

    a. View the custom template definition.

    b. Use a helper function to understand the necessary arguments.

    c. Run the custom template.

Prerequisites

You need two separate Snowflake accounts to complete this flow. Use the first account to execute the provider’s commands, then switch to the second account to execute the consumer’s commands.

Provider

Note

The following commands should be run in a Snowflake worksheet in the provider account.

Set up the environment

Execute the following commands to set up the Snowflake environment before using developer APIs to work with a Snowflake Data Clean Room. If you don’t have the SAMOOHA_APP_ROLE role, contact your account administrator.

use role samooha_app_role;
use warehouse app_wh;
Copy

Create the clean room

Create a name for the clean room. Enter a new clean room name to avoid colliding with existing clean room names. Note that clean room names can only be alphanumeric. Clean room names cannot contain special characters other than spaces and underscores.

set cleanroom_name = 'Custom Template Demo Clean room';
Copy

You can create a new clean room with the clean room name set above. If the clean room name set above already exists as an existing clean room, this process will fail.

This procedure takes approximately 45 seconds to run.

The second argument to provider.cleanroom_init is the distribution of the clean room. This can either be INTERNAL or EXTERNAL. For testing purposes, if you are sharing the clean room to an account in the same organization, you can use INTERNAL to bypass the automated security scan which must take place before an application package is released to collaborators. However, if you are sharing this clean room to an account in a different organization, you must use an EXTERNAL clean room distribution.

call samooha_by_snowflake_local_db.provider.cleanroom_init($cleanroom_name, 'INTERNAL');
Copy

In order to view the status of the security scan, use:

call samooha_by_snowflake_local_db.provider.view_cleanroom_scan_status($cleanroom_name);
Copy

Once you have created your clean room, you must set its release directive before it can be shared with any collaborator. However, if your distribution was set to EXTERNAL, you must first wait for the security scan to complete before setting the release directive. You can continue running the remainder of the steps while the scan runs and return here before the provider.create_cleanroom_listing step.

In order to set the release directive, call:

call samooha_by_snowflake_local_db.provider.set_default_release_directive($cleanroom_name, 'V1_0', '0');
Copy

Cross-region sharing

In order to share a clean room with a Snowflake customer whose account is in a different region than your account, you must enable Cross-Cloud Auto-Fulfillment. For information about the additional costs associated with collaborating with consumers in other regions, see Cross-Cloud Auto-Fulfillment costs.

When using developer APIs, enabling cross-region sharing is a two-step process:

  1. A Snowflake administrator with the ACCOUNTADMIN role enables Cross-Cloud Auto-Fulfillment for your Snowflake account. For instructions, see Collaborate with accounts in different regions.

  2. You execute the provider.enable_laf_for_cleanroom command to enable Cross-Cloud Auto-Fulfillment for the clean room. For example:

    call samooha_by_snowflake_local_db.provider.enable_laf_for_cleanroom($cleanroom_name);

    Copy

After you have enabled Cross-Cloud Auto-Fulfillment for the clean room, you can add consumers to your listing as usual using the provider.create_cleanroom_listing command. The listing is automatically replicated to remote clouds and regions as needed.

Add a custom analysis templates to the clean room

To add a custom analysis template to the clean room you need a placeholder for table names on both the provider and consumer sides, along with join columns from the provider side. In SQL Jinja templates, these placeholders must always be:

  • source_table: an array of table names from the provider

  • my_table: an array of table names from the consumer

Table names can be made dynamic through using these variables, but they can also be hardcoded into the template if desired using the name of the view linked to the clean room. Column names can either be hardcoded into the template, if desired, or set dynamically through parameters. If they are set through parameters, remember that you need to call the parameters dimensions or measure_column, which need to be arrays, in order for them to be checked against the column policy. You add these as SQL Jinja parameters in the template that will be passed in later by the consumer when querying. The join policies ensure that the consumer cannot join on columns other than the authorized ones.

Alternatively, any argument in a custom SQL Jinja template can be checked for compliance with the join and column policies using the following filters:

  • join_policy: checks if a string value or filter clause is compliant with the join policy

  • column_policy: checks if a string value or filter clause is compliant with the column policy

  • join_and_column_policy: checks if columns used for a join in a filter clause are compliant with the join policy, and that columns used as a filter are compliant with the column policy

For example, in the clause {{ provider_id | sqlsafe | join_policy }}, an input of p.HEM will be parsed to check if p.HEM is in the join policy. Note: Only use the sqlsafe filter with caution as it allows collaborators to put pure SQL into the template.

Note

All provider/consumer tables must be referenced using these arguments since the name of the secure view actually linked to the clean room will be different to the table name. Critically, provider table aliases MUST be p (or p1), p2, p3, p4, etc. and consumer table aliases must be c (or c1), c2, c3, etc. This is required in order to enforce security policies in the clean room.

Note that this function overrides any existing template with the same name. If you want to update any existing template, you can simply call this function again with the updated template.

call samooha_by_snowflake_local_db.provider.add_custom_sql_template(
    $cleanroom_name,
    'prod_custom_template',    // Name of the template
    $$
select
count(*) as total_count
from identifier({{ my_table[0] }}) c
inner join identifier({{ source_table[0] }}) p
on identifier({{ consumer_id | join_policy }}) = identifier({{ provider_id | join_policy }})
{% if where_clause %}
where {{ where_clause | sqlsafe | column_policy }}
{% endif %};
    $$                         // A string representing the SQL Jinja template
);
Copy

If you want to view the templates that are currently active in the clean room, call the following procedure.

call samooha_by_snowflake_local_db.provider.view_added_templates($cleanroom_name);
Copy

Any template added to the clean room can also be cleared away if needed. Please see the Provider API Reference Guide for more details.

Set the column policy on each table

Display the data linked to see the columns present inside the table. To view the top 10 rows, call the following procedure.

select * from SAMOOHA_SAMPLE_DATABASE_NAV2.DEMO.CUSTOMERS limit 10;
Copy

Set the columns that the consumer can group on, aggregate (e.g. SUM/AVG) and generally uses in an analysis for every table and template combination. This gives flexibility so that the same table can allow different column selections depending on the underlying template. This should only be called after adding the template.

Note that the column policy is replace only, so if the function is called again, then the previously set column policy is completely replaced by the new one.

Column policy should not be used on identity columns like email, HEM, RampID, etc. since you don’t want the consumer to be able to group by these columns. In the production environment, the system will intelligently infer PII columns and block this operation, but this feature is not available in the sandbox environment. It should only be used on columns that you want the consumer to be able to aggregate and group by, like Status, Age Band, Region Code, Days Active, etc.

Note that for the “column_policy” and “join_policy” to carry out checks on the consumer analysis requests, all column names MUST be referred to as dimensions or measure_columns in the SQL Jinja template. Please make sure you use these tags to refer to columns you want to be checked in custom SQL Jinja templates.

call samooha_by_snowflake_local_db.provider.set_column_policy($cleanroom_name, [
    'prod_custom_template:SAMOOHA_SAMPLE_DATABASE_NAV2.DEMO.CUSTOMERS:STATUS',
    'prod_custom_template:SAMOOHA_SAMPLE_DATABASE_NAV2.DEMO.CUSTOMERS:AGE_BAND',
    'prod_custom_template:SAMOOHA_SAMPLE_DATABASE_NAV2.DEMO.CUSTOMERS:DAYS_ACTIVE']);
Copy

If you want to view the column policy that has been added to the clean room, call the following procedure.

call samooha_by_snowflake_local_db.provider.view_column_policy($cleanroom_name);
Copy

Share with a consumer

Finally, add a data consumer to the clean room by adding their Snowflake account locator and account names as shown below. The Snowflake account name must be of the form <ORGANIZATION>.<ACCOUNT_NAME>.

Note

In order to call the following procedures, make sure you have first set the release directive using provider.set_default_release_directive. You can see the latest available version and patches using:

show versions in application package samooha_cleanroom_Custom_Template_Demo_clean_room;
Copy

Note

Note this call takes about 60 seconds to complete, since it sets up a number of tasks for listening and logging requests from the consumer.

call samooha_by_snowflake_local_db.provider.add_consumers($cleanroom_name, '<CONSUMER_ACCOUNT_LOCATOR>', '<CONSUMER_ACCOUNT_NAME>');
call samooha_By_snowflake_local_db.provider.create_cleanroom_listing($cleanroom_name, '<CONSUMER_ACCOUNT_NAME>');
Copy

Multiple consumer account locators can be passed into the provider.add_consumers function as a comma separated string, or as separate calls to provider.add_consumers.

If you want to view the consumers who have been added to this clean room, call the following procedure.

call samooha_by_snowflake_local_db.provider.view_consumers($cleanroom_name);
Copy

View the clean rooms that have been recently created via the following procedure:

call samooha_by_snowflake_local_db.provider.view_cleanrooms();
Copy

View more insights on the clean room recently created via the following procedure.

call samooha_by_snowflake_local_db.provider.describe_cleanroom($cleanroom_name);
Copy

Any clean room created can also be deleted. The following command drops the clean room entirely, so any consumers who previously had access to the clean room will no longer be able to use it. If a clean room with the same name is desired in the future, it must be re-initialized using the above flow.

call samooha_by_snowflake_local_db.provider.drop_cleanroom($cleanroom_name);
Copy

Note

The provider flow is now finished. Please switch to the consumer account to continue with consumer flow.

Consumer

Note

The following commands should be run in a Snowflake worksheet in the consumer account

Set up the environment

Execute the following commands to set up the Snowflake environment before using developer APIs to work with a Snowflake Data Clean Room. If you don’t have the SAMOOHA_APP_ROLE role, contact your account administrator.

use role samooha_app_role;
use warehouse app_wh;
Copy

Install the clean room

Once a clean room share has been installed, the list of clean rooms available can be viewed using the below command.

call samooha_by_snowflake_local_db.consumer.view_cleanrooms();
Copy

Assign a name for the clean room that the provider has shared with you.

set cleanroom_name = 'Custom Template Demo Clean room';
Copy

The following command installs the clean room on the consumer account with the associated provider and selected clean room.

This procedure takes approximately 45 seconds to run.

call samooha_by_snowflake_local_db.consumer.install_cleanroom($cleanroom_name, '<PROVIDER_ACCOUNT_LOCATOR>');
Copy

Once the clean room has been installed, the provider has to finish setting up the clean room on their side before it is enabled for use. The below function allows you to check the status of the clean room. Once it has been enabled, you should be able to run the Run Analysis command below. It typically takes about 1 minute for the clean room to be enabled.

call samooha_by_snowflake_local_db.consumer.is_enabled($cleanroom_name);
Copy

Run the analysis

Now that the clean room is installed, you can run the analysis template given to the clean room by the provider using a “run_analysis” command. You can see how each field is determined in the sections below.

The number of datasets that can be passed is constrained by the template that the provider has implemented. Some templates require a specific number of tables. The template creator can impose the requirements they wish to support.

Note

Before running the analysis, you can alter the warehouse size, or use a new, bigger, warehouse size if your tables are large.

call samooha_by_snowflake_local_db.consumer.run_analysis(
  $cleanroom_name,              -- cleanroom
  'prod_custom_template',       -- template name

  ['SAMOOHA_SAMPLE_DATABASE_NAV2.DEMO.CUSTOMERS'],    -- your tables
  ['SAMOOHA_SAMPLE_DATABASE_NAV2.DEMO.CUSTOMERS'],       -- provider tables

  object_construct(                              -- The keyword arguments needed for the SQL Jinja template

    'consumer_id', 'c.hem',                    -- Consumer column to join on, needed by template

    'provider_id', 'p.hem',                    -- Provider column to join on, needed by template

    'where_clause', 'p.STATUS = $$MEMBER$$' -- Boolean filter for custom template
  )
);
Copy

For each of the columns referred to in either the dataset filtering “where_clause”, or the dimensions or measure_columns, you can use p. to refer to fields in provider tables, and c. to refer to fields in consumer tables. Use p2, p3, etc. for more than one provider table and c2, c3, etc. for more than one consumer table.

How to determine the inputs to run_analysis

To run the analysis, you need to pass in some parameters to the run_analysis function. This section will show you how to determine what parameters to pass in.

Template names

First, you can see the supported analysis templates by calling the following procedure.

call samooha_by_snowflake_local_db.consumer.view_added_templates($cleanroom_name);
Copy

Before running an analysis with a template, you need to know what arguments to specify and what types are expected. For custom templates, you can execute the following.

call samooha_by_snowflake_local_db.consumer.view_template_definition($cleanroom_name, 'prod_custom_template');
Copy

This can often also contain a large number of different SQL Jinja parameters. The following functionality parses the SQL Jinja template and extracts the arguments that need to be specified in run_analysis into a list.

call samooha_by_snowflake_local_db.consumer.get_arguments_from_template($cleanroom_name, 'prod_custom_template');
Copy

Dataset names

If you want to view the dataset names that have been added to the clean room by the provider, call the following procedure. Note that you cannot view the data present in the datasets that have been added to the clean room by the provider due to the security properties of the clean room.

call samooha_by_snowflake_local_db.consumer.view_provider_datasets($cleanroom_name);
Copy

You can also see the tables you’ve linked to the clean room by using the following call:

call samooha_by_snowflake_local_db.consumer.view_consumer_datasets($cleanroom_name);
Copy

Dimension and measure columns

While running the analysis, you might want to filter, group by and aggregate on certain columns. If you want to view the column policy that has been added to the clean room by the provider, call the following procedure.

call samooha_by_snowflake_local_db.consumer.view_provider_column_policy($cleanroom_name);
Copy

Common errors

If you are getting Not approved: unauthorized columns used error as a result of run analysis, you might want to view the join policy and column policy set by the provider again.

call samooha_by_snowflake_local_db.consumer.view_provider_join_policy($cleanroom_name);
call samooha_by_snowflake_local_db.consumer.view_provider_column_policy($cleanroom_name);
Copy

It is also possible that you have exhausted your privacy budget, which prevents you from executing more queries. Your remaining privacy budget can be viewed using the below command. It resets daily, or the clean room provider can reset it if they wish.

call samooha_by_snowflake_local_db.consumer.view_remaining_privacy_budget($cleanroom_name);
Copy

You can check if Differential Privacy has been enabled for your clean room using the following API:

call samooha_by_snowflake_local_db.consumer.is_dp_enabled($cleanroom_name);
Copy
